CYPD3171-24LQXQ Integrated Circuit Chip EZ-PD™ CCG3PA USB Type-C Port Controller
CYPD3171-24LQXQ Integrated Circuit Chip EZ-PD™ CCG3PA USB Type-C Port Controller
Description
Part Number:
CYPD3171-24LQXQ
Series:
EZ-PD™ CCG3PA
Applications:
USB Type C
Core Processor:
ARM® Cortex®-M0
Program Memory Type:
FLASH (64kB)
Voltage - Supply:
3V ~ 24.5V
CYPD3171-24LQXQ Integrated Circuit Chip EZ-PD™ CCG3PA USB Type-C Port Controller
Product Description Of CYPD3171-24LQXQ
CYPD3171-24LQXQ EZ-PD™ CCG3PA is Infineon’s highly integrated USB Type-C port controller that complies with the latest USB Type-C and PD standards and is targeted for PC power adapters, mobile chargers, car chargers, and power bank applications.
CYPD3171-24LQXQ EZ-PD™ CCG3PA uses Infineon’s proprietary M0S8 technology with a 32-bit Arm® Cortex® -M0 processor, 64-KB flash, a complete Type-C USB PD transceiver, all termination resistors required for a Type-C port, integrated feedback control circuitry for voltage (VBUS) regulation, and system-level ESD protection. It is available in 24-pin QFN packages.
Specification Of CYPD3171-24LQXQ
Part Number:
CYPD3171-24LQXQ
Product Category:
USB Interface IC
USB Controllers
Power Delivery
SMD/SMT
QFN-24
USB-C 3.0
Full Speed (FS)
1 Mb/s
2.7 V
5.5 V
10 mA
- 40 ℃
+ 105 ℃
Core:
ARM Cortex M0
Interface Type:
Serial
Number of Ports:
1 Port
Operating Supply Voltage:
2.7 V to 5.5 V
Features Of CYPD3171-24LQXQ
• Type-C support and USB PD support
- Supports USB PD Revision 3.1 including programmable power supply (PPS) mode
- Configurable resistors RP and RD
- Supports one USB Type-C port and one Type-A port
• 2x legacy/proprietary charging blocks
- Supports QC 4.0, Apple charging 2.4A, AFC, BC 1.2
- Integrates all required terminations on DP/DM lines
• Integrated voltage (VBUS) regulation and current sense amplifier
- Analog regulation of secondary side feedback node (direct feedback or opto coupler)
- Integrated shunt regulator function for VBUS control
- Constant current or constant voltage mode
- Supports low-side current sensing for constant current control
• System-level fault protection
- VBUS to CC short protection
- On-chip OVP, OCP, UVP, and SCP
- Supports OTP through integrated ADC circuit
• 32-bit MCU subsystem
- Arm® Cortex®-M0 CPU
- 64KB Flash
- 8KB SRAM
• Clocks and oscillators
- Integrated oscillator eliminating the need for external clock
• Power: 3.0-V to 24.5-V operation (30-V tolerant)
• Packages: 24-pin QFN
• Supports extended industrial temperature range (–40°C to +105°C)
Applications Of CYPD3171-24LQXQ
Body electronics and lighting
Battery powered power tools
Adapters and chargers
