SIM7000C Wireless Communication Module Multi-Band LTE-TDD/LTE-FDD And Dual-Band GPRS/EDGE Wireless Modules

SIM7000C Wireless Communication Module Multi-Band LTE-TDD/LTE-FDD And Dual-Band GPRS/EDGE Wireless Modules

Product Description Of SIM7000C

SIM7000C is a multi-band LTE-TDD/LTE-FDD and dual-band GPRS/EDGE wireless module. The module adopts SMT package and supports LTECAT-M1 (eMTC), NB-IoT and GPRS/EDGE, with data transmission speed up to 375Kbps.SIM7000C has rich interfaces including UART, USB2.0, GPIO, etc., which makes the module has rich expandability and provides great convenience for user's product development. This also enables the module to have rich expandability, which provides great convenience for users' product development.

Product Advantages Of SIM7000C

• Low Power Consumption: The module has low power consumption and can theoretically be supported by two #5 batteries for 10 years.

• Wide coverage: Compared with GSM, LTE CAT-M1 and NB-IoT have strong gain and wide signal coverage, which makes the product capable of wireless communication in basement-like locations.

• Smooth Upgrade: The module size is 24*24mm, and most of the PintoPin and AT commands are compatible with SIM800 series and SIM900 series, which is convenient for users to smoothly upgrade to LTE network.

Feature Of SIM7000C

• Single-Band TDD-LTE B39

• Quad-Band FDD-LTE B1/B3/B5/B8

• GPRS/EDGE 900/1800 MHz

• Output power

• GSM900: 2W

• DCS1800: 1W

• Control Via AT Commands

• Supply voltage range: 3.0V~ 4.3V,Typ:3.8V

• Operation temperature: -40°C to +85°C

• Dimension: 24 X 24x 2.6mm

• Weight: 3.0g

• GNSS (GPS,GLONASS and BeiDou/Compass,Galileo, QZSS)

Applications Of SIM7000C

• Internet of Things Applications

• Metering

• Remote control

• Asset tracking

• Remote monitoring

• Telemedicine

• Mobile POS terminals

• Shared bicycle
