ADV7535BCBZ Integrated Circuit Chip MIPI/DSI Receiver With HDMI Transmitter WLCSP-49

ADV7535BCBZ Integrated Circuit Chip MIPI/DSI Receiver With HDMI Transmitter WLCSP-49​

Product Description Of ADV7535BCBZ

ADV7535BCBZ provides a MIPI® display serial interface (MIPI/ DSI) input receiver and a High-Definition Multimedia Interface (HDMI®) transmitter output. The DSI receiver input supports DSI video mode operation only, and specifically, only supports non-burst mode with sync pulses. The DSI receiver provides up to four lanes of MIPI/DSI data, each running up to 891 Mbps. The HDMI transmitter supports video resolutions up to a maximum TMDS clock frequency of 148.5 MHz. The ADV7535 also provides an audio input port, which supports the insertion of audio into the HDMI stream.

Fabricated in an advanced CMOS process, the ADV7535BCBZ is available in a space saving, 49-ball, WLCSP surface-mount package. This package is RoHS-compliant and specified to operate from −10°C to +85°C.

Specification Of ADV7535BCBZ

Features Of ADV7535BCBZ

Low power MIPI/DSI receiver
Low power HDMI/DVI transmitter ideal for portable applications
CEC controller and expanded message buffer (3 messages) reduces system overhead
Compatible with DVI v.1.0
Embedded HDCP keys to support HDCP 1.3
1.8 V and 3.3 V supplies for ultralow operating power
Audio inputs accept logic levels from 1.8V to 3.3V

Applications Of ADV7535BCBZ

Mobile devices
Cellular handsets
Digital video cameras
Digital still cameras
Personal media players
Gaming
