DRV8210PDSGR Integrated Circuit Chip 12V 1A H-Bridge Motor Driver With Low Power Sleep Mode

DRV8210PDSGR Integrated Circuit Chip 12V 1A H-Bridge Motor Driver With Low Power Sleep Mode

Product Description Of DRV8210PDSGR

DRV8210PDSGR is an integrated motor driver with four N-channel power FETs, charge pump regulator, and protection circuitry. The tripler charge pump architecture allows the device to operate down to 1.65 V to accommodate 1.8-V supply rails and low-battery conditions. The charge pump integrates all capacitors to reduce the overall solution size of the motor driver on a PCB and allows for 100% duty cycle operation.

DRV8210PDSGR supports an industry standard PWM (IN1/IN2) control interface. The nSLEEP pin controls a low-power sleep mode which achieves ultra-low quiescent current draw by disabling the internal circuitry.

Specification Of DRV8210PDSGR

Features Of DRV8210PDSGR

• N-channel H-bridge motor driver

• MOSFET on-resistance: HS + LS 1 Ω

• Drives one bidirectional brushed DC motor

• One single- or dual-coil latching relay

• 1.65-V to 11-V operating supply voltage range

• High output current capability: 1.76-A peak

• Standard PWM Interface (IN1/IN2)

• Supports 1.8-V, 3.3-V, and 5-V logic inputs

• Ultra low-power sleep mode

• <84.5 nA @ VVM = 5 V, VVCC = 3.3 V, TJ = 25°C

• Protection features

• Undervoltage lockout (UVLO)

• Overcurrent protection (OCP)

• Thermal shutdown (TSD)

Applications Of DRV8210PDSGR

• Brushed DC motor, solenoid, & relay driving

• Water, gas, & electricity meters

• IP network camera IR cut filter

• Video doorbell

• Machine vision camera

• Electronic smart lock

• Electronic and robotic toys

• Blood pressure monitors

• Infusion pumps

• Electric toothbrush

• Beauty & grooming
