Product Details:
|
| Part Number: | VN7008AJTR | Output Configuration: | High Side |
|---|---|---|---|
| Voltage - Load: | 4V ~ 28V | Current - Output (Max): | 70A |
| Rds On (Typ): | 8.5mOhm | Operating Temperature: | -40°C ~ 150°C (TJ) |
VN7008AJTR Integrated Circuit Chip High-Side Driver 96A High Side Switches PowerSSO-16
Product Description Of VN7008AJTR
VN7008AJTR is a single channel high-side driver manufactured using ST proprietary VIPower® technology and housed in PowerSSO-16 package.
VN7008AJTR is designed to drive 12 V automotive grounded loads through a 3 V and 5 V CMOS-compatible interface, and to provide protection and diagnostics.
VN7008AJTR integrates advanced protective functions such as load current limitation, overload active management by power limitation and overtemperature shutdown with configurable latch-off.
Specification Of VN7008AJTR
| Part Number: | VN7008AJTR |
| Product Category: | Power Switch ICs - Power Distribution |
| Current Limit: | 96 A |
| Maximum Operating Temperature: | + 150℃ |
| Minimum Operating Temperature: | - 40℃ |
| Moisture Sensitive: | Yes |
| Mounting Style: | SMD/SMT |
| Number of Outputs: | 1 Output |
| Off Time - Max: | 100 us |
| On Resistance - Max: | 17 mOhms |
| On Time - Max: | 120 us |
| Operating Supply Voltage: | 4 V to 28 V |
| Output Current: | 5 A |
| Package / Case: | PowerSSO-16 |
| Product Type: | Power Switch ICs - Power Distribution |
| Subcategory: | Switch ICs |
| Supply Voltage - Max: | 28 V |
| Supply Voltage - Min: | 4 V |
| Type: | High Side |
Features Of VN7008AJTR
Single channel smart high side driver with CS analog feedback
Very low standby current
Compatible with 3 V and 5 V CMOS outputs
CS diagnostic functions
Analog feedback of: load current with high precision proportional current mirror
Overload and short to ground (power limitation) indication
Thermal shutdown indication
OFF-state open-load detection
Output short to VCC detection
Sense enable/ disable
Protections
Undervoltage shutdown
Overvoltage clamp
Load current limitation
Self limiting of fast thermal transients
Configurable latch-off on overtemperature or power limitation with dedicated fault reset pin
Loss of ground and loss of VCC
Reverse battery with external components
Electrostatic discharge protection
Applications Of VN7008AJTR
All types of Automotive resistive, inductive and capacitive loads
Specially intended for Automotive Headlamps
