ISL83082EIUZ Integrated Circuit Chip 5V Full Fail-Safe RS-485/RS-422 Transceivers MSOP-8
ISL83082EIUZ Integrated Circuit Chip 5V Full Fail-Safe RS-485/RS-422 Transceivers MSOP-8
Description
Part Number:
ISL83082EIUZ
Number Of Drivers::
1 Driver
Number Of Receivers::
1 Receiver
Data Rate::
115 Kb/s
Supply Voltage - Max::
5 V
Supply Voltage - Min::
5 V
Highlight:
ISL83082EIUZ
,
ISL83082EIUZ Integrated Circuit Chip
,
Full Fail-Safe RS-485/RS-422 Transceivers
ISL83082EIUZ Integrated Circuit Chip 5V Full Fail-Safe RS-485/RS-422 Transceivers MSOP-8
Product Description Of ISL83082EIUZ
ISL83082EIUZ is BiCMOS, ESD protected, 5V powered, single transceivers that meet both the RS-485 and RS-422 standards for balanced communication. Each driver output, and receiver input, is protected against ±15kV ESD strikes without latch-up, and unlike competitive products, this Intersil family is specified for 10% tolerance supplies (4. 5V to 5. 5V).
Specification Of ISL83082EIUZ
1 Driver
1 Receiver
115 kb/s
5 V
5 V
- 40 C
+ 85 C
Height:
0 mm
Length:
3 mm
Operating Supply Voltage:
5 V
Features Of ISL83082EIUZ
Pb-free Available (RoHS Compliant)
RS-485 I/O Pin ESD Protection ±15kV HBM Class 3 ESD Protection (HBM) on all Pins >7kV
Tiny MSOP Packages Save 50% Board Space
Full Fail-safe (Open, Short, Terminated and Floating) Receivers
Hot Plug Circuitry (ISL83080E, ISL83082E, ISL83083E, ISL83085E)
Tx and Rx Outputs Remain Three-state During Power-up/Power-down
True 1/8 Unit Load Allows up to 256 Devices on the Bus
Specified for Single 5V, 10% Tolerance, Supplies
High Data Rates up to 10Mbps
Low Quiescent Supply Current 530µA Ultra Low Shutdown Supply Current70nA
-7V to +12V Common Mode Input Voltage Range
Half and Full Duplex Pinouts
Three-State Rx and Tx Outputs (Except ISL83084E)
Current Limiting and Thermal Shutdown for driver Overload Protection
Applications Of ISL83082EIUZ
Automated Utility Meter Reading Systems
High Node Count Systems
Factory Automation
Field Bus Networks
Security Camera Networks
Building Environmental Control Systems
Industrial/Process Control Networks
