Product Details:
|
Part Number: | AD835ARZ | Function: | Analog Multiplier |
---|---|---|---|
Number Of Bits/Stages: | 4-Quadrant | Pd - Power Dissipation: | 300 MW |
Operating Supply Current: | 16 MA | Type: | Voltage Output 4-Quadrant Multiplier |
Highlight: | AD835ARZ,AD835ARZ Integrated Circuit Chip,250MHz Analog Multipliers |
AD835ARZ Integrated Circuit Chip Voltage Output 4-Quadrant Multipliers 250MHz Analog Multipliers
Product Description Of AD835ARZ
AD835ARZ is a complete four-quadrant, voltage output analog multiplier, fabricated on an advanced dielectrically isolated complementary bipolar process.
AD835ARZ generates the linear product of its X and Y voltage inputs with a −3 dB output bandwidth of 250 MHz (a small signal rise time of 1 ns). Full-scale (−1 V to +1 V) rise to fall times are 2.5 ns (with a standard RL of 150 Ω), and the settling time to 0.1% under the same conditions is typically 20 ns.
Specification Of AD835ARZ
Part Number: | AD835ARZ |
Multipliers | |
1 Circuit | |
SOIC-8 | |
5 V | |
5 V | |
SMD/SMT | |
- 40 ℃ | |
+ 85 ℃ | |
Input Voltage: | 1 V |
Operating Supply Current: | 16 mA |
Operating Supply Voltage: | 5 V |
Output Voltage: | 2.5 V |
Pd - Power Dissipation: | 300 mW |
Product Type: | Multipliers / Dividers |
Features Of AD835ARZ
Simple: Basic Function is W = XY + Z
High Differential Input Impedance X, Y, and Z Inputs
DC-Coupled Voltage Output Simplifies Use
Very Fast: Settles to 0.1% of FS in 20 ns
Complete: Minimal External Components Required
Low Multiplier Noise: 50 nV/√Hz
Applications Of AD835ARZ
Very fast multiplication, division, squaring
Wideband modulation and demodulation
Phase detection and measurement
Sinusoidal frequency doubling
Video gain control and keying
Voltage-controlled amplifiers and filters
