BTS3405G Integrated Circuit Chip Two Channel Automotive Smart Low-Side Switch
Product Description Of BTS3405G
BTS3405G is a two channel low-side power switch in PG-DSO-8-25 package providing embedded protective functions.
BTS3405G device consists of two separate monolithic IC. Each with one N-channel power MOSFET transistor and additional protection circuitry.
Specifications Of BTS3405G
|
Current Limit:
|
600 mA
|
|
Maximum Operating Temperature:
|
+ 150 C
|
|
Minimum Operating Temperature:
|
- 40 C
|
|
Number of Outputs:
|
2 Output
|
|
Off Time - Max:
|
45 us
|
|
On Resistance - Max:
|
700 mOhms
|
|
On Time - Max:
|
38 us
|
|
Output Current:
|
350 mA
|
|
Pd - Power Dissipation:
|
780 mW
|
|
Supply Voltage - Max:
|
10 V
|
|
Supply Voltage - Min:
|
- 200 mV
|
|
Unit Weight:
|
83 mg
|
Feature Of BTS3405G
Low input current
Short circuit and Overload protection
Current limitation
Input protection (ESD)
Thermal protection with auto restart
Compatible to standard Power MOSFET
Analog driving possible
Two channel concept saves PCB footprint
Green Product (RoHS compliant)
AEC Qualified
Applications Of BTS3405G
Dual channel
Automotive protected
Relay driver
Automotive 48 V battery management system (BMS)
Automotive body control module (BCM)
General purpose motor drive - variating frequency and voltage
Secondary power distribution system
