CYW43362KUBGT WIFI 6 Chip Single-Chip Integrated IEEE 802.11™ Wi-Fi 4 Chip

CYW43362KUBGT WIFI 6 Chip Single-Chip Integrated IEEE 802.11™ Wi-Fi 4 Chip

Product Description Of CYW43362KUBGT
CYW43362KUBGT single-chip device provides the highest level of integration for mobile and handheld wireless systems, featuring integrated IEEE 802.11™ b/g and handheld device class IEEE 802.11n. It includes a 2.4 GHz WLAN CMOS power amplifier(PA) that meets the output power requirements of most handheld systems. An optional external low-noise amplifier (LNA) and external PA are also supported.

Feature Of CYW43362KUBGT
Single-band 2.4 GHz IEEE 802.11 b/g/n
Integrated WLAN CMOS power amplifier with internal power detector and closed-loop power control
Internal fractional-N PLL enables the use of a wide range of reference clock frequencies
Supports IEEE 802.15.2 external 3-wire and 4-wire coexistence schemes to optimize bandwidth utilization with other co-located wireless technologies such as Bluetooth, Zigbee,or BT Smart.
Supports standard interfaces SDIO v2.0 (50 MHz, 4-bit and 1-bit) and generic SPI (up to 50 MHz)
Integrated ARM Cortex™-M3 CPU with on-chip memory enables running IEEE 802.11 firmware that can be fieldupgraded with future features.
Supports WMM®, WMM-PS, and Wi-Fi Voice Personal (upgradable to Voice Enterprise in the future)
Programmable dynamic power management
Supports battery voltage range from 2.3V to 4.8V supplies with internal switching regulator
1 kbit One-Time Programmable (OTP) memory for storing board parameters
69-bump WLBGA (4.52 mm x 2.92 mm, 0.4 mm pitch)

Applications Of CYW43362KUBGT
Home appliances
Security Camera and Video Doorbell
