MAX17330X22 Integrated Circuit Chip Stand-Alone Fuel Gauge With Integrated Precision Charger And Protector
MAX17330X22 Integrated Circuit Chip Stand-Alone Fuel Gauge With Integrated Precision Charger And Protector
Description
Part Number:
MAX17330X22
Output Voltage::
1.8 V
Operating Supply Voltage::
2.16 V To 4.9 V
Operating Supply Current::
52 UA
MAX17330X22 Integrated Circuit Chip Stand-Alone Fuel Gauge With Integrated Precision Charger And Protector
Product Description Of MAX17330X22
MAX17330X22 is a 28μA IQ stand-alone charger, fuel gauge, protector, and battery internal self-discharge detection IC for 1-cell lithium-ion/polymer batteries. When a voltage source is present, the MAX17330 regulates charging by modulating the charge N-FET, using AccuCharge™ charger technology.
Specifications Of MAX17330X22
Fuel Gauges
Lithium-ion, Lithium Polymer
1.8 V
2.16 V to 4.9 V
Maximum Operating Temperature:
+ 85 C
Minimum Operating Temperature:
- 40 C
Operating Supply Current:
52 uA
Feature Of MAX17330X22
Non-Volatile Programmable Stand-Alone AccuCharge Charger
0.2% Charge Voltage 3.6V to 4.8V, Configurable
1% Charge Current, 256 Current Settings
FET Temperature Limit and Heat Regulation
Prequal and Step-Charging Options
JEITA—6 Temperature Regions
Battery Health + Programmable Safety/Protection
Overvoltage/Overcharge-Current
Temperature Region Dependent
Overcharge/Discharge/Short-Circuit Current
Over/Under Temperature
Zero-Volt or Greater than 1.8V Charging Option
Undervoltage + SmartEmpty
Pushbutton Wakeup/Factory Ship Mode (0.5μA)
ModelGauge m5 EZ Algorithm
Percent, Capacity, Time-to-Empty/Full, Age
Cycle+™ Age Forecast
Dynamic Power—Estimates Power Capability
SHA-256 Authentication to Prevent Cloning
Precision Measurement Without Calibration
Current, Voltage, Power, Time, Cycles
Die Temperature and two Thermistors>
History Logging, User Data
Low Quiescent Current
FETs Enabled: 28µA Active, 21µA Hibernate>
FETs Disabled: 8µA Ship, 0.5µA/0.1µA Shutdown
2-wire (I2C/SMBus™)
1.9mm x 2.5mm 15-bump 0.5mm pitch WLP
Applications Of MAX17330X22
Dual Screen Smartphones, Tablets
Handheld Radios, Computers, Accessories
Hearables, Wearables, Smartwatches
Home/Building Automation, Sensors, Cameras
Medical Devices, Health, Fitness Monitors
Parallel Battery AR/VR Systems
Smart Batteries and Hybrid Supercap Batteries
USB PPS and Direct Charging
