ATM90E26-YU Integrated Circuit Chip Energy Metering IC SSOP-28 Single Phase Meter IC

ATM90E26-YU Integrated Circuit Chip Energy Metering IC SSOP-28 Single Phase Meter IC​

Product Description Of ATM90E26-YU

ATM90E26-YU is Single-Phase High-Performance Wide-Span Energy Metering IC.

ATM90E26-YU is a high-performance wide-span energy metering chip. The ADC and DSP technology ensure the chip's longterm stability over variations in grid and ambient environmental conditions.

Specification Of ATM90E26-YU

Features Of ATM90E26-YU

• 3.3V single power supply. Operating voltage range: 2.8~3.6V. Metering accuracy guaranteed within 3.0V~3.6V. 5V compatible for digital input.
• Built-in hysteresis for power-on reset.
• Selectable UART interface and SPI interface (four-wire SPI interface or simplified three-wire SPI interface with fixed 24 cycles for all registers operation).
• Parameter diagnosis function and programmable interrupt output of the IRQ interrupt signal and the WarnOut signal.
• Programmable voltage sag detection and zero-crossing output.
• Channel input range
- Voltage channel (when gain is '1'): 120μVrms~600mVrms.
- L line current channel (when gain is '24'): 5μVrms~25mVrms.
- N line current channel (when gain is '1'): 120μVrms~600mVrms.
• Programmable L line current gain: 1, 4, 8, 16, 24; Programmable N line gain: 1, 2, 4.
• Support L line and N line offset compensation.
• CF1 and CF2 output active and reactive energy pulses respectively which can be used for calibration or energy accumulation.
• Crystal oscillator frequency: 8.192 MHz.
• Green SSOP28 package.
• Operating temperature: -40 ℃ ~ +85 ℃ .

Applications Of ATM90E26-YU

ATM90E26-YU is used for active and reactive energy metering for single-phase two-wire (1P2W), single-phase three-wire (1P3W) or anti-tampering energy meters. With the measurement function, the M90E26 can also be used in power instruments which need to measure voltage, current, etc.
