USB5906CT/KD Integrated Circuit Chip 6-Port USB USB 3.2 Gen Hight -Speed SmartHub™ Controller
Product Description Of USB5906CT/KD
USB5906CT/KD SmartHub™ is a 6 port, SuperSpeed (SS), low power, configurable USB3.2 Gen1 hub and fully compliant with USB-IF's USB3.2 Gen1 specification. The USB5906CT/KD also supports Hi-Speed (HS), Full Speed (FS) and Low Speed (LS) USB signaling, offering complete coverage of all defined USB operating speeds. The new SuperSpeed hubs operate in parallel with the USB 2.0 controller, so 5 Gbps SuperSpeed data transfers are not affected by slower USB 2.0 traffic.
Feature Of USB5906CT/KD
Six downstream USB3.2 Gen1/2.0 ports w/ support for a single USB Type-C upstream port
Integrated Hub Feature Controller (HFC) enabling I/O Bridging and FlexConnect
USB to I²C/SPI/GPIO bridge endpoint support
Reversible upstream and downstream Port 1 roles on command
Integrated 2:1 MUX for direct support of the new USB Type-C ports
Integrated Billboard class device for Power Delivery notification support
PortSplitting - USB downstream port can be split for custom applications using embedded USB3 devices in parallel with USB2.0 device
Battery Charging - USB-IF rev1.2 support on downstream ports (DCP, CDP, SDP) including legacy Apple®
Port Config Straps - Predefined configuration of port settings – Battery Charging ports, Non-Removable ports, Disabled ports
USB Link Power Management (LPM) support
IETF RFC 4122 compliant 128-bit UUID
Compatible with Microsoft® Windows®, Apple OS X, and Linux hub drivers
Available in 100-pin (12mm x 12mm) VQFN RoHS compliant package
Industrial grade temperature support (−40°C to +85°C)
Applications Of USB5906CT/KD
Standalone USB Hubs
Laptop Docks
PC Motherboards
PC Monitor Docks
Multi-function USB 3.2 Gen 1 Peripherals
