88E1512-A0-NNP2I000 Ethernet IC 10/100/1000Mbps Energy Efficient Ethernet Transceiver

88E1512-A0-NNP2I000 Ethernet IC 10/100/1000Mbps Energy Efficient Ethernet Transceiver ​

Product Description Of 88E1512-A0-NNP2I000

88E1512-A0-NNP2I000 is a physical layer device containing a single 10/100/1000 Gigabit Ethernet transceiver. The transceiver implements the Ethernet physical layer portion of the 1000BASE-T, 100BASE-TX, and 10BASE-T standards.

88E1512-A0-NNP2I000 is manufactured using standard digital CMOS process and contains all the active circuitry required to implement the physical layer functions to transmit and receive data on standard CAT 5 unshielded twisted pair.

Features Of 88E1512-A0-NNP2I000

10/100/1000BASE-T IEEE 802.3 compliant Multiple Operating Modes
RGMII to Copper
SGMII to Copper
RGMII to Fiber/SGMII
RGMII to Copper/Fiber/SGMII with Auto-Media Detect
Copper to Fiber (1000BASE-X)
Four RGMII timing modes including integrated delays - This eliminates the need for adding trace delays on the PCB
Supports 1000BASE-X and 100BASE-FX on the Fiber interface along with SGMII  Supports LVCMOS I/O Standards on the RGMII
Supports Energy Efficient Ethernet (EEE) - IEEE 802.3az-2010 compliant
EEE Buffering
Incorporates EEE buffering for seamless support of legacy MACs
Ultra Low Power
Integrated MDI termination resistors that eliminate passive components
Integrated Switching Voltage Regulators
Supports Green Ethernet
Active Power Save Mode
Energy Detect and Energy Detect+ low power modes

Auto-Calibration for MAC Interface outputs
Temperature Sensor
Supports single 3.3V supply when using internal switching regulator
I/O pads can be supplied with 1.8V, 2.5V, or 3.3V
56-Pin QFN 8 mm x 8 mm Green package with EPAD
