BSM150GB120DN2 Automotive IGBT Modules 1200V 150A Half-Bridge IGBT Power Module

Large Image : BSM150GB120DN2 Automotive IGBT Modules 1200V 150A Half-Bridge IGBT Power Module

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	BSM150GB120DN2

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	MODULE
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

BSM150GB120DN2 Automotive IGBT Modules 1200V 150A Half-Bridge IGBT Power Module

Description

Part Number:	BSM150GB120DN2	Configuration:	Half Bridge
Voltage - Collector Emitter Breakdown (Max):	1200 V	Current - Collector (Ic) (Max):	210 A
Power - Max:	1250 W	Operating Temperature:	150°C (TJ)

BSM150GB120DN2 Automotive IGBT Modules 1200V 150A Half-Bridge IGBT Power Module

Product Description Of BSM150GB120DN2

BSM150GB120DN2 is 1200V, 210A Half Bridge IGBT Module, Chassis Mount Module.

Specification Of BSM150GB120DN2

Part Number:	BSM150GB120DN2
Product:	IGBT Silicon Modules
Configuration:	Half Bridge
Collector- Emitter Voltage VCEO Max:	1.2 kV
Collector-Emitter Saturation Voltage:	2.5 V
Continuous Collector Current at 25 C:	210 A
Gate-Emitter Leakage Current:	320 nA
Pd - Power Dissipation:	1.25 kW
Package / Case:	Half Bridge2
Minimum Operating Temperature:	- 40 ℃
Maximum Operating Temperature:	+ 150 ℃
Maximum Gate Emitter Voltage:	20 V
Mounting Style:	Screw Mount
Product Type:	IGBT Modules

Features Of BSM150GB120DN2

VCE=1200V
Ic=210A
Half-bridge
Including fast free-wheeling diodes
Package with insulated metal base plate

Product Photo Of BSM150GB120DN2
