MAX14752EUE Integrated Circuit Chip 72V 8-Channel Analog Multiplexers TSSOP-16

MAX14752EUE Integrated Circuit Chip 72V 8-Channel Analog Multiplexers TSSOP-16​

Product Description Of MAX14752EUE

MAX14752EUE is Ideal for Industrial Applications such as PLCs, Industrial Controllers and ATE Equipment

MAX14752EUE is 8-Channel high-voltage analog multiplexers. The device feature 60Ω (typ) on-resistance with 0.03Ω (typ) on-resistance flatness. These low on-resistance multiplexers conduct equally well in either direction. Flexible logic levels for the channel-select interface are defined by the EN input.

MAX14752EUE is a 8-to-1 multiplexer. It operate with dual supplies of ±10V to ±36V, or a single supply of +20V to +72V.

Specification Of MAX14752EUE

Features Of MAX14752EUE

Supply Range Accommodates Wide Voltage Applications
- Wide ±36V (max) Bipolar Power Supply
- High +72V (max) Single Power Supply
- Asymmetric Bipolar Power Supply Operation
Low Leakage Current and RON Improves System Accuracy
- Low On-Resistance 60Ω (typ)
- 0.03Ω (typ) RON Flatness Over Common-Mode Voltage Range
- 20nA Low-Input, On-Leakage Current (max)
Low 25µA IDD Supply Current in Disable Mode Saves Power
Easy to Upgrade with Pin Compatible Industry- Standard DG408/DG409

Applications Of MAX14752EUE

ATE Systems
Environment Control Systems
Medical Monitoring Systems
Programmable-Logic Controllers
