LM27761DSGR Integrated Circuit Chip Low-Noise Regulated Inverter with Integrated LDO

LM27761DSGR Integrated Circuit Chip Low-Noise Regulated Inverter with Integrated LDO

Product Description Of LM27761DSGR
LM27761DSGR low-noise regulated switched-capacitor voltage inverter delivers a very low-noise adjustable output for an input voltage in the range of 2.7 V to 5.5 V. Four low-cost capacitors are used in the application solution to provide up to 250 mA of output current. The regulated output for the device is adjustable between −1.5 V and −5 V. LM27761DSGR operates at 2-MHz (typical) switching frequency to reduce output resistance and voltage ripple. With an operating current of only 370 µA (charge-pump power efficiency greater than 80% with most loads) and 7-µA typical shutdown current, LM27761DSGR provides ideal performance when driving power amplifiers, DAC bias rails, and other high-current, low-noise voltage applications.

Specifications Of LM27761DSGR

Features Of LM27761DSGR
Inverts and Regulates the Input Supply Voltage
Low Output Ripple
Shutdown Lowers Quiescent Current to 7 µA (Typical)
Up to 250-mA Output Current
2.5-Ω Inverter Output Impedance, VIN = 5 V
±4% Regulation at Peak Load
370-µA Quiescent Current
2-MHz (Typical) Low-Noise Fixed-Frequency Operation
35-dB (Typical) LDO PSRR at 2 MHz
With 80-mA Load Current
30-mV LDO Dropout Voltage at 100 mA,
VOUT = –5 V
Current Limit and Thermal Protection

Applications Of LM27761DSGR
Operational Amplifier Power
Wireless Communication Systems
Cellular-Phone Power-Amplifier Biasing
Interface Power Supplies
Handheld Instrumentation
Hi-Fi Headphone Amplifiers
Powering Data Converters
