IRS2110SPBF Integrated Circuit Chip 500V EiceDRIVER™ Gate Driver IC With Shutdown

Description
Part Number: IRS2110SPBF Type: High-Side, Low-Side
Product: IGBT, MOSFET Gate Drivers Number Of Drivers: 2 Driver
Output Current: 2.5 A Pd - Power Dissipation: 1.25 W

IRS2110SPBF Integrated Circuit Chip 500V EiceDRIVER™ Gate Driver IC With Shutdown​



Product Description Of IRS2110SPBF

IRS2110SPBF is 500V high-side and low-side gate driver IC with shutdown.

IRS2110SPBF——EiceDRIVER™ 500 V high and low side gate driver IC with typical 2.5 A source and 2.5 A sink currents in 16 Lead SOICWB package for IGBTs and MOSFETs.


Specification Of IRS2110SPBF

Driven Configuration
Half-Bridge
Channel Type
Independent
Number of Drivers
2
Gate Type
IGBT, N-Channel MOSFET
Voltage - Supply
10V ~ 20V
Logic Voltage - VIL, VIH
6V, 9.5V
Current - Peak Output (Source, Sink)
2.5A, 2.5A
Input Type
Non-Inverting
High Side Voltage - Max (Bootstrap)
500 V
Rise / Fall Time (Typ)
25ns, 17ns
Operating Temperature
-40°C ~ 150°C (TJ)
Mounting Type
Surface Mount
Package / Case
16-SOIC (0.295", 7.50


Features Of IRS2110SPBF

Floating gate driver designed for bootstrap operation
Fully operational to +500 V
Fully operational to +600 V option available (IRS2113 )
Tolerant to negative transient voltage, dV/dt immune
Gate drive supply range from 10 V to 20 V
Undervoltage lockout for both channels
3.3 V logic compatible
Separate logic supply range from 3.3 V to 20 V
Matched propagation delay for both channels
Logic and power ground +/- 5 V offset
CMOS Schmitt-triggered inputs with pull-down
Cycle by cycle edge-triggered shutdown logic
Outputs in phase with inputs



Applications Of IRS2110SPBF

Light electric vehicles (LEV)
Motor Control
Photovoltaic
Power conversion
Power tools
