RFFM4227TR13 Wireless Communication Module Wi-Fi Low Noise Amplifier

RFFM4227TR13 Wireless Communication Module Wi-Fi Low Noise Amplifier

Product Description Of RFFM4227TR13
RFFM4227TR13 is a low noise amplifier (LNA) designed for Wi-Fi 802.11b/g/n systems. The integrated input and output 50Ω match minimizes layout are a in the customer’s application, reduces the bill of materials and manufacturability cost. Performance is focused on a balance of low noise and gain that increases the receive sensitivity.
RFFM4227TR13 integrates a bypass path that enables a defined gain step. The device is provided in a 1.6mm x 1.6mm x 0.5mm, 6-pin DFN package.

Specification Of RFFM4227TR13

Features Of RFFM4227TR13
2400 – 2500 MHz
15 dB LNA Gain
1.3 dB Noise Figure
6 dB Bypass Loss
Input and Output Matched to 50 Ω
Integrated 5 GHz Rejection Filter
1.6 x 1.6 mm DFN Package

Applications Of RFFM4227TR13
Wireless Routers
Access Points
Residential Gateways
Customer Premise Equipment
Internet of Things
