MT61M256M32JE-12 AAT:A Memory IC Chip 8Gbit Parallel GDDR6 SGRAM Memory IC FBGA-180

MT61M256M32JE-12 AAT:A Memory IC Chip 8Gbit Parallel GDDR6 SGRAM Memory IC FBGA-180

Product Description Of MT61M256M32JE-12 AAT:A

MT61M256M32JE-12 AAT:A is 2-Channels 8Gbit Parallel GDDR6 SGRAM Memory IC for Networking.

MT61M256M32JE-12 AAT:A——The GDDR6 SGRAM is a high-speed dynamic random-access memory designed for applications requiring high bandwidth. It is internally configured as 16‐bank memory and contains 8,589,934,592 bits.

Specification Of MT61M256M32JE-12 AAT:A

Features Of MT61M256M32JE-12 AAT:A

• VDD = VDDQ = 1.25V –3%/+6%
• VPP = 1.8V –3%/+6%
• Data rate: 10 Gb/s, 12 Gb/s
• 2 separate independent channels (x16)
• x16/x8 and 2-channel/pseudo channel (PC) mode configurations set at reset
• Single ended interfaces per channel for command/ address (CA) and data
• On‐chip temperature sensor with read‐out
• Auto precharge option for each burst access
• Auto refresh mode (32ms, 16k cycles) with per-bank and per-2-bank refresh options
• Temperature sensor controlled self refresh rate
• Digital tRAS lockout
• On‐die termination (ODT) for all high‐speed inputs
• Pseudo open drain (POD125) compatible outputs
• ODT and output driver strength auto calibration with external resistor ZQ pin (120Ω)
• Internal VREF with DFE for data inputs, with input receiver characteristics programmable per pin
• Selectable external or internal VREF for CA inputs; programmable VREF offsets for internal VREF
• Vendor ID for device identification
• IEEE 1149.1 compliant boundary scan
• 180-ball BGA package
• Lead-free (RoHS-compliant) and halogen-free packaging
• TC = 0°C to +95°C (Commercial) and –40°C to +95°C (Industrial)
