TPS65381AQDAPRQ1 Integrated Circuit Chip Multi-Rail Power Supply IC HTSSOP-32

TPS65381AQDAPRQ1 Integrated Circuit Chip Multi-Rail Power Supply IC HTSSOP-32​

Product Description Of TPS65381AQDAPRQ1

TPS65381AQDAPRQ1 is a multirail power supply designed to supply microcontrollers (MCUs) in safety-relevant applications, such as those found in automotive and industrial markets.

TPS65381AQDAPRQ1 supports Texas Instruments’ Hercules™ TMS570 MCU and C2000™ MCU families, and various other MCUs with dual-core lockstep (LS) or loosely-coupled architectures (LC).

TPS65381AQDAPRQ1 integrates multiple supply rails to power the MCU, controller area network (CAN), or FlexRay, and an external sensor. An asynchronous-buck switch-mode power-supply converter with an internal FET converts the input supply (battery) voltage to a 6-V preregulator output. This 6-V preregulator supplies the other regulators. The device supports wakeup from IGNITION or wakeup from the CAN transceiver.

Specification Of TPS65381AQDAPRQ1

Features Of TPS65381AQDAPRQ1

• Multirail Power Supply Supporting Among Others
– TI Hercules™ TMS570, C2000™, and Various Functional-Safety Architecture Microcontrollers
• Supply Rails
– Input voltage range:
– 5.8 V to 36 V (CAN, I/O, MCU Core, and Sensor-Supply Regulators Functional)
– 4.5 V to 5.8 V (3.3 V I/O and MCU Core Regulators Functional)
– 6-V Asynchronous Switch Mode Preregulator With Internal FET, 1.3-A Output Current
– 5-V (CAN) Supply Voltage, Linear Regulator With Internal FET, 300-mA Output Current
– 3.3-V or 5-V (MCU I/O) Voltage, Linear Regulator With Internal FET, 300-mA Output Current
– 0.8-V to 3.3-V Adjustable (MCU Core Voltage), Linear Regulator Controller With External FET
– 3.3-V to 9.5-V Adjustable Sensor Supply: Linear Tracking Regulator With Internal FET, 100-mA Output Current, and Protection Against Short-toSupply and Short-to Ground
– Charge Pump: Typically 12 V Above Battery Voltage

Applications Of TPS65381AQDAPRQ1
• Safety Automotive Applications
– Power Steering: Electrical Power Steering (EPS) and Electro Hydraulic Power Steering (EHPS)
– Braking: Anti-Lock Brake System (ABS), Electronic Stability Control (ESC), and Electric Parking Brake
– Advanced Driver Assistance Systems (ADAS)
– Suspension
• Industrial Safety Applications
– Safety Programmable-Logic Controllers (PLCs)
– Safety I/O Control Modules
– Test and Measurement
– Railway and Subway Signal Control and Safety Modules
– Elevator and Escalator Safety Control
– Wind Turbine Control
