IKW40N65H5 Integrated Circuit Chip High Speed 650V 40A IGBT Transistors TO-247-3

Large Image : IKW40N65H5 Integrated Circuit Chip High Speed 650V 40A IGBT Transistors TO-247-3

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	IKW40N65H5

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-247-3
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

IKW40N65H5 Integrated Circuit Chip High Speed 650V 40A IGBT Transistors TO-247-3

Description

Part Number:	IKW40N65H5	Voltage - Collector Emitter Breakdown (Max):	650 V
Current - Collector (Ic) (Max):	74 A	Current - Collector Pulsed (Icm):	120 A
Vce(on) (Max) @ Vge, Ic:	2.1V @ 15V, 40A	Power - Max:	255 W
Highlight:	IKW40N65H5 , IKW40N65H5 Integrated Circuit Chip , 650V 40A IGBT Transistors

IKW40N65H5 Integrated Circuit Chip High Speed 650V 40A IGBT Transistors TO-247-3

Product Description Of IKW40N65H5
IKW40N65H5 is high speed 650 V, 40 A hard-switching TRENCHSTOPTM IGBT5 co-packed with RAPID 1 fast and soft anti-parallel diode in a TO-247 package, is defined as "best-in-class" IGBT.

Specification Of IKW40N65H5

Voltage - Collector Emitter Breakdown (Max)	650 V
Current - Collector (Ic) (Max)	74 A
Current - Collector Pulsed (Icm)	120 A
Vce(on) (Max) @ Vge, Ic	2.1V @ 15V, 40A
Power - Max	255 W
Switching Energy	390µJ (on), 120µJ (off)
Input Type	Standard
Gate Charge	95 nC
Td (on/off) @ 25°C	22ns/165ns
Test Condition	400V, 20A, 15Ohm, 15V
Reverse Recovery Time (trr)	62 ns
Operating Temperature	-40°C ~ 175°C (TJ)

Features Of IKW40N65H5
650 V breakthrough voltage
Compared to best-in-class HighSpeed 3 family
Factor 2.5 lower Qg
Factor 2 reduction in switching losses
200mV reduction in VCEsat
Co-packed with Rapid Si-diode technology
Low COES/EOSS
Mild positive temperature coefficient VCEsat
Temperature stability of Vf

Benefits Of IKW40N65H5
Best-in-class efficiency, resulting in lower junction and case temperature leading to higher device reliability
50 V increase in the bus voltage possible without compromising reliability
Higher power density design

Applications Of IKW40N65H5
Uninterruptible power supply (UPS)
Industrial heating and welding
Bringing a whole new lifestyle and health experience to today’s connected citizen
Energy Storage Systems
Residential air conditioning: Smart (IoT) and efficient cooling
Uninterruptible power supplies (UPS)
