LT6011CS8 Integrated Circuit Chip 135µA Rail-To-Rail Output Precision Operational Amplifier

LT6011CS8 Integrated Circuit Chip 135µA Rail-To-Rail Output Precision Operational Amplifier

Product Description Of LT6011CS8
LT6011CS8 op amps combine low noise and high precision input performance with low power consumption and rail-to-rail output swing.
Input offset voltage is trimmed to less than 60µV. The low drift and excellent long-term stability guarantee a high accuracy over temperature and time. The 300pA maximum input bias current and 120dB minimum voltage gain further maintain this precision over operating conditions.

Specification Of LT6011CS8

Features Of LT6011CS8
60µV Maximum Offset Voltage
300pA Maximum Input Bias Current
135µA Supply Current per Amplifier
Rail-to-Rail Output Swing
120dB Minimum Voltage Gain, VS = ±15V
0.8µV/°C Maximum VOS Drift
14nV/√Hz Input Noise Voltage
2.7V to ±18V Supply Voltage Operation
Operating Temperature Range: –40°C to 85°C
Space Saving 3mm x 3mm DFN Package

Applications Of LT6011CS8
Thermocouple Amplifiers
Precision Photo Diode Amplifiers
Instrumentation Amplifiers
Battery-Powered Precision Systems
Low Voltage Precision Systems
