TPS53626RSMR Integrated Circuit Chip 2-Phase D-CAP+™ Step-Down Controller VQFN-32

TPS53626RSMR Integrated Circuit Chip 2-Phase D-CAP+™ Step-Down Controller VQFN-32​

Product Description Of TPS53626RSMR

TPS53626RSMR is a driverless, VR13 SVID compliant, synchronous buck controller. Advanced control features such as D-CAP+ architecture with overlapping pulse support undershoot reduction (USR) and overshoot reduction (OSR) provide fast transient response, lowest output capacitance and high efficiency.

TPS53626RSMR also supports single-phase operation in CCM or DCM for light-load efficiency boost. The device integrates a full set of VR13 I/O features including VR_READY (PGOOD), ALERT and VR_HOT. The SVID interface address allows programming from 00h to 07h. Adjustable control of VOUT slew rate can be programmed as high as 20mV/uS.

TPS53626RSMR device package is a space saving, thermally enhanced 32-pin VQFN package that operates from –40°C to 105°C.

Specification Of TPS53626RSMR

Features Of TPS53626RSMR

Intel VR13 Serial VID (SVID) Compliant
1- or 2-Phase Operation
Default Configuration Mode for VR13 VCCIO and VMCP
Supports Both Droop and Non-Droop Applications
8-Bit DAC with 5-mV Step
Output Range: 0.25 V to 1.52 V
Optimized Efficiency at Light and Heavy Loads
8 Independent Levels of Overshoot Reduction (OSR) and Undershoot Reduction (USR)
Driverless Configuration for Efficient High-Frequency Switching
Supports Discrete, Power Block, Power Stage or DrMOS MOSFET Implementations
Accurate, Adjustable Voltage Positioning
300-kHz to 1-MHz Frequency Selections
Patented AutoBalance Phase Balancing
Programmable ON-Pulse Extension for Load Transient Boost
Programmable Auto DCM and CCM Operation
Selectable 8-level Current Limit
4.5-V to 28-V Conversion Voltage Range
Small, 4 mm × 4 mm, 32-Pin, VQFN PowerPad Package
