MAX4715EXK Integrated Circuit Chip 400mOhm Single-Supply SPST Analog Switches SC70-5

MAX4715EXK Integrated Circuit Chip 400mOhm Single-Supply SPST Analog Switches SC70-5

Product Description Of MAX4715EXK

MAX4715EXK is low on-resistance, low-voltage, single-pole/single-throw (SPST) analog switches that operate from a +1.6V to +3.6V single supply. The MAX4715EXK is normally open (NO), it have fast switching speeds (tON = 18ns max, tOFF = 12ns max).

Specification Of MAX4715EXK

Features Of MAX4715EXK

Low RON
- 0.4Ω max (+3V Supply)
- 1.2Ω max (+1.8V Supply)
0.1Ωtryi max RON Flatness (+3V Supply)
+1.6V to +3.6V Single-Supply Operation
Available in 5-Pin SC70 Packages
Fast Switching: tON = 18ns max, tOFF = 12ns max
+1.8V CMOS Logic Compatible (+3V Supply)

Applications Of MAX4715EXK
Audio/Video Signal Routing
Battery-Powered Applications
Cell Phones
Communication Systems
Hard Drives
Low-Voltage Data Acquisition
Modems
PCMCIA Cards
Power Routing
