Product Description Of IGW20N60H3
IGW20N60H3 is high speed 600 V, 20 A single TRENCHSTOP™ IGBT3 Transistors in a TO247 package provides the best compromise between switching and conduction losses. The key feature of this family is a MOSFET-like turn-off switching behavior, leading to low turn off losses.
Specifications Of IGW20N60H3
Si
TO-247-3
Through Hole
Single
600 V
1.95 V
- 20 V, 20 V
40 A
170 W
- 40 C
+ 175 C
Gate-Emitter Leakage Current:
100 nA
Unit Weight:
6.047 g
Features Of IGW20N60H3
Low switching losses for high efficiency
Excellent Vce(sat) behavior thanks to the famous Infineon TRENCHSTOP™ technology
Fast switching behavior with low EMI emissions
Low gate resistor selection possible (down to 5Ω) whilst maintaining excellent switching behaviour
Short circuit capability 5µs
Offering Tj(max) of 175°C
Packaged with and without freewheeling diode for increased design freedom
Benefits Of IGW20N60H3
Low switching and conduction losses
Very good EMI behavior
Can be used with a small gate resistor for reduced delay time and voltage overshoot
High current density
Best-in-class 600 V IGBT efficiency and EMI behavior
Applications Of IGW20N60H3
Photovoltaic
Uninterruptible power supplies (UPS)
