REF3425IDBVR Integrated Circuit Chip 2.5V Series Voltage Reference IC SOT-23-6

REF3425IDBVR Integrated Circuit Chip 2.5V Series Voltage Reference IC SOT-23-6

Product Description Of REF3425IDBVR

REF3425IDBVR is a low temperature drift (6 ppm/°C), low-power, high-precision CMOS voltage reference, featuring ±0.05% initial accuracy, low operating current with power consumption less than 95 µA.
REF3425IDBVR also offers very low output noise of 3.8 µVp-p /V, which enables its ability to maintain high signal integrity with high-resolution data converters in noise critical systems.

Specification Of REF3425IDBVR

Features Of REF3425IDBVR

Initial accuracy: ±0.05% (maximum)
Temperature coefficient : 6 ppm/°C (maximum)
Operating temperature range: −40°C to +125°C
Output current: ±10 mA
Low quiescent current: 95 µA (maximum)
Ultra-low zero load dropout voltage: 100 mV (maximum)
Wide input voltage: 12 V
Output 1/f noise (0.1 Hz to 10 Hz): 3.8 µVp-p/V
Excellent long-term stability 25 ppm/1000 hrs

Applications Of REF3425IDBVR

Data acquisition systems
Analog I/O modules
Field transmitters
Lab & field instrumentation
Servo drive control modules
DC power supply, AC source, electronic load
