Product Description Of SGM809-TXN3L
SGM809-TXN3L is integrated microprocessor supervisory devices. Compared with the design using a single IC or discrete components, this integration design has the advantage of improving system stability and accuracy.

The devices can be reset under power-up, power-down or even voltage reduction brownout conditions. When VCC is as low as 1V, the reset output can still operate. On the power-on state, the internal timer maintains a 240ms reset assertion that keeps the microprocessor in the reset state until the condition is stable.

Feature Of SGM809-TXN3L
Superior Upgrade for MAX803/MAX809/MAX810 and ADM803/ADM809/ADM810
High Accuracy Fixed Detection Options: 1.8V, 2.5V, 3V, 3.3V and 5V
Low Current Consumption: 13μA (TYP)
150ms (MIN) Power-On Reset
Reset Output Options:
Open-Drain RESET Output: SGM803
Push-Pull RESET Output: SGM809
Push-Pull RESET Output: SGM810
Reset Assertion Down to 1V VCC
-40℃ to +125℃ Operating Temperature Range
Available in Green SOT-23-3 and SOT-23 Packages

Applications Of SGM809-TXN3L
Computers
Battery-Powered Applications
Portable Equipment
Automotive Equipment
Controllers
Intelligent Instruments
Critical µP Power Monitoring
