MP6501AGF Integrated Circuit Chip 2.5A Bipolar Stepper Motor Driver TSSOP-28

MP6501AGF Integrated Circuit Chip 2.5A Bipolar Stepper Motor Driver TSSOP-28

Product Description Of MP6501AGF
MP6501AGF is a stepper motor driver with a built-in micro stepping translator. It operates from a supply voltage of up to 35V and can deliver motor current up to 2.5A. MP6501AGF can operate a bipolar stepper motor in full-, half-, quarter-, and eighth- step modes. Internal safety features include over-current protection, input over-voltage protection, UVLO and thermal shutdown. The part has a fixed 3.3V reference output, which allows it to operate without any control power supply and work with any microcontroller. Ron of the switches is as low as 230mO. Current sensing is done by external resistors. The MP6501AGF comes in a space-saving TSSOP-28 package with exposed thermal pad.

Specification Of MP6501AGF

Feature Of MP6501AGF
Wide 8.5V to 35V Input Voltage Range
Two Internal Full Bridge PWM Converters
Low On Resistance(HS:220mO; LS:220mO)
No Control Power Supply Required
Simple Logic Interface
3.3 and 5 V Compatible Logic Supply
Full-, Half-, Quarter-, and Eighth- Step Functionality
2.5A Maximum Output Current
Adjustable Mixed Decay Ratio
Over-Current Protection
Input OVP Function
Thermal Shutdown and UVLO Protection
Space-saving TSSOP-28 EP Package
Fault Indication Output

Applications Of MP6501AGF
Bipolar Stepper Motors
Printers
