ADUM4224WCRWZ Integrated Circuit Chip 5kVrms Isolated Precision Half-Bridge Gate Drivers

ADUM4224WCRWZ Integrated Circuit Chip 5kVrms Isolated Precision Half-Bridge Gate Drivers​

Product Description Of ADUM4224WCRWZ

ADUM4224WCRWZ is 4A isolated, half-bridge gate drivers that employ the Analog Devices, Inc., iCoupler® technology to provide independent and isolated high-side and low-side outputs. The ADUM4224WCRWZ provides 5000 V rms isolation in the wide-body, 16-lead SOIC package.
ADUM4224WCRWZ isolators each provide two independent isolated channels. It operate with an input supply ranging from 3.0 V to 5.5 V, providing compatibility with lower voltage systems.

Specification Of ADUM4224WCRWZ

Features​ Of ADUM4224WCRWZ

4A peak output current
Working voltage:
High-side or low-side relative to input: 537V peak
High frequency operation: 1MHz maximum
3.3V to 5V CMOS input logic
4.5V to 18V output drive
Precise timing characteristics:
59ns maximum isolator and driver propagation delay
5ns maximum channel-to-channel matching
CMOS input logic levels
High common-mode transient immunity: >25kV/μs
Enhanced system-level ESD performance per IEC 61000-4-x
High junction temperature operation: 125°C
Default low output

Applications Of ADUM4224WCRWZ

Switching power supplies
Isolated IGBT/MOSFET gate drives
Industrial inverters
