Product Description Of INA199C3RSWR
INA199C3RSWR voltage-output, current-shunt monitors (also called current-sense amplifiers) are commonly used for overcurrent protection, precision-current measurement for system optimization, or in closed-loop feedback circuits. This series of devices can sense drops across shunt resistors at common-mode voltages from –0.3 V to 26 V, independent of the supply voltage. Three fixed gains are available: 50 V/V, 100 V/V, and 200 V/V. The low offset of the zero-drift architecture enables current sensing with maximum drops across the shunt as low as 10-mV full-scale.

These devices operate from a single 2.7-V to 26-V power supply, drawing a maximum of 100 µA of supply current. All versions are specified from –40°C to 125°C, and offered in thin UQFN-10 packages.

Specification Of Of INA199C3RSWR

Feature Of INA199C3RSWR
Wide Common-Mode Range: –0.3 V to 26 V
Offset Voltage: ±150 µV (Maximum) (Enables Shunt Drops of 10-mV Full-Scale)
Accuracy:
Gain Error (Maximum Over Temperature):
±1% (C Version)
±1.5% (A and B Versions)
0.5-µV/°C Offset Drift (Maximum)
10-ppm/°C Gain Drift (Maximum)
Choice of Gains:INA199x3: 200 V/V
Quiescent Current: 100 µA (Maximum)
Packages: 10-Pin UQFN

Applications Of INA199C3RSWR
Notebook Computers
Cell Phones
Qi-Compliant Wireless Charging Transmitters
Telecom Equipment
Power Management
Battery Chargers
