BUF16821AIPWPRQ1 Integrated Circuit Chip Automotive Gamma-Voltage Generator And Vcom Calibrator

BUF16821AIPWPRQ1 Integrated Circuit Chip Automotive Gamma-Voltage Generator And Vcom Calibrator

Product Description Of BUF16821AIPWPRQ1
BUF16821AIPWPRQ1 offers 16 programmable gamma channels and two programmable VCOM channels. The final gamma and VCOM values can be stored in the on-chip, nonvolatile memory. To allow for programming errors or liquid crystal display (LCD) panel rework, the device supports up to 16 write operations to the on-chip memory.

Specification Of BUF16821AIPWPRQ1

Features Of BUF16821AIPWPRQ1
AEC-Q100 Qualified with:
Temperature Grade 3: –40°C to 85°C
HBM ESD Classification 2
CDM ESD Classification C4B
16-Channel P-Gamma, 2-Channel P-VCOM, 10-Bit Resolution
16x Rewritable Nonvolatile Memory
Two Independent Pin-Selectable Memory Banks
Rail-to-Rail Output:
300-mV (Min) Swing-to-Rail (10 mA)
> 300-mA (Max) IOUT
Supply Voltage: 9 V to 20 V
Digital Supply: 2 V to 5.5 V
I2C™ Interface: Supports 400 kHz and 2.7 MHz

Application Of BUF16821AIPWPRQ1
TFT-LCD Reference Drivers
