MCP3202-CI/SN Integrated Circuit Chip 12-Bit 100kSPS Dual Channel Analog To Digital Converters

MCP3202-CI/SN Integrated Circuit Chip 12-Bit 100kSPS Dual Channel Analog To Digital Converters

Product Description Of MCP3202-CI/SN
MCP3202-CI/SN is a successive approximation 12-bit analog-to-digital (A/D) converter with on-board sample and hold circuitry.

MCP3202-CI/SN is programmable to provide a single pseudo-differential input pair or dual single-ended inputs.

Specification Of MCP3202-CI/SN

Features Of MCP3202-CI/SN
12-bit resolution
±1 LSB maximum DNL
±2 LSB maximum INL
Analog inputs programmable as single-ended orpseudo-differential pairs
On-chip sample and hold
SPI Serial Interface (Modes 0,0 and 1,1)
Single supply operation: 2.7V-5.5V
100 ksps maximum sampling rate at VDD = 5V
50 ksps maximum sampling rate at VDD = 2.7V
Low power CMOS technology
500 nA typical standby current, 5 µA maximum
550 µA maximum active current at 5V
Industrial temp range: -40°C to +85°C

Application Of MCP3202-CI/SN
Sensor Interface
Process Control
Data Acquisition
Battery Operated Systems

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
