LT3092IST Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source

LT3092IST Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source

Product Description Of LT3092IST
LT3092IST is a programmable 2-terminal current source. It requires only two resistors to set an output current between 0.5mA and 200mA. A multitude of analog techniques lend themselves to actively programming the output current. LT3092IST is stable without input and output capacitors, offering high DC and AC impedance. This feature allows operation in intrinsically safe applications.

The SET pin features 1% initial accuracy and low temperature coefficient. Current regulation is better than 10ppm/V from 1.5V to 40V.

LT3092IST can operate in a 2-terminal current source configuration in series with signal lines. It is ideal for driving sensors, remote supplies, and as a precision current limiter for local supplies.

Specification Of LT3092IST

Features Of LT3092IST
Programmable 2-Terminal Current Source
Maximum Output Current: 200mA
Wide Input Voltage Range: 1.2V to 40V
Input/Output Capacitors Not Required
Resistor Ratio Sets Output Current
Initial Set Pin Current Accuracy: 1%
Reverse-Voltage Protection
Reverse-Current Protection
<0.001%/V Line Regulation Typical
Current Limit and Thermal Shutdown Protection

Application Of LT3092IST
2-Terminal Floating Current Source
GND Referred Current Source
Variable Current Source
In-Line Limiter
Intrinsic Safety Circuits
