IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors

IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors
IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors
IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors

Large Image :  IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPD50P04P4L-11
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TO252-3
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors

Description
Part Number: IPD50P04P4L-11 Transistor Polarity:: P-Channel
Number Of Channels:: 1 Channel Vds - Drain-Source Breakdown Voltage:: 40 V
Id - Continuous Drain Current:: 50 A Rds On - Drain-Source Resistance:: 17.2 MOhms

IPD50P04P4L-11 Integrated Circuit Chip P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors



Product Description Of IPD50P04P4L-11
IPD50P04P4L-11is -40V P-Channel 10.6mΩ OptiMOS™-P2 Automotive MOSFET Transistors.



Specification Of IPD50P04P4L-11

P-Channel

1 Channel

40 V

50 A

17.2 mOhms

- 16 V, + 5 V

1.2 V

45 nC

- 55 C

+ 175 C

58 W

Fall Time:

39 ns

Height:

2.3 mm

Length:

6.5 mm

Product Type:

MOSFETs

Rise Time:

9 ns

Typical Turn-Off Delay Time:

46 ns

Typical Turn-On Delay Time:

12 ns

Width:

6.22 mm

Unit Weight:

330 mg



Features Of IPD50P04P4L-11
P-channel - Logic Level - Enhancement mode
AEC qualified
MSL1 up to 260°C peak reflow
175°C operating temperature
Green Product (RoHS compliant)
100% Avalanche tested
Intended for reverse battery protection



Benefits Of IPD50P04P4L-11
No charge pump required for high side drive.
Simple interface drive circuit
World's lowest RDSon at 40V
Highest current capability
Lowest switching and conduction power losses for highest thermal efficiency
Robust packages with superior quality and reliability



Applications Of IPD50P04P4L-11
High-Side MOSFETs for motor bridges (half-bridges, H-bridges, 3-phase-motors)
Bridge configuration could be realized with 40V P-Channel as high side device with no need of charge pump
Simulation/SPICE-Model
Automotive body control module (BCM)
Electric vehicle (EV) drivetrain system
EV traction inverter
Multi-port fuel injection
On-board charging (OBC) for electric vehicles
