BCM53134SKFBG Ethernet IC Six-Port Ultra Low-Power Gigabit Ethernet Switch

BCM53134SKFBG Ethernet IC Six-Port Ultra Low-Power Gigabit Ethernet Switch

Product Description Of BCM53134SKFBG
BCM53134SKFBG is Broadcom's lowest power consumption integrated Ethernet switch for next-generation Home Gateway, SOHO/SMB and wireless router applications. Building on the industry-leading 28 nm RoboSwitch™ architecture, the BCM53134SKFBG allows customers to significantly reduce power consumption of existing designs, while delivering higher performance to meet the growing bandwidth demands in the home and SOHO/SMB environments.

Features Of BCM53134SKFBG
4xGPHY integrated, 1xRGMII and 1xRGMII/SGMII+ (1G/2.5 Gb/s) interfaces
Cost-effective, Ultra low power (green power saving modes supported), smart-managed Gigabit switch with Integrated on-chip 8051
microcontroller for
Advanced bridging with
4K MAC Table (also-known- as FDB, ARL or Learning tables)
802.1q vlan bridging
Port based Vlan filtering
802.1ad (QinQ)
Up to 8 spanning trees
128 multicast groups
Advanced QoS features with
8 queues per port (2 dedicated for time sensitive applications)
IEEE 802.1p, MAC Port, TOS, and DiffServ Class-Of- Service mapping
SP, WRR, WDRR scheduling and combinations of the three
RED/WRED and tail-drop congestion avoidance mechanisms
Rate control protecting against traffic flooding of unknown unicasts/broadcasts/
Advanced Compact Field Processor (CFP)
128 CFP rules
L1 to L4 filtering (physical ports to TCP/UDP ports)
Advanced Two-Rate Three Color Metering (compliant with RFC2698, RFC 4115 and MEF 10.2)
Broadsync™ HD for IEEE 802.1AS support
Two dedicated queues for time sensitive traffic
Time stamping ingress and egress CPU generated frames
Time slot transmission received for Broadsync traffic.

Applications Of BCM53134SKFBG
Broadband Access Devices
