BCM5464RA1KFBG Ethernet IC Quad-Port 10/100/1000BASE-T Gigabit Copper Ethernet Transceiver

BCM5464RA1KFBG Ethernet IC Quad-Port 10/100/1000BASE-T Gigabit Copper Ethernet Transceiver​

Product Description Of BCM5464RA1KFBG

BCM5464RA1KFBG is Quad-Port Gigabit Copper Ethernet PHY Transceiver, it consists of four complete 10/100/1000BASE-T Gigabit Ethernet transceivers integrated on a single monolithic CMOS chip.

BCM5464RA1KFBG is optimized for low-power and small footprint size to enable high port density applications. BCM5464RA1KFBG enables a new class of cost-effective Gigabit Ethernet equipment by lowering system cost and reducing power dissipation by nearly 25%, driving the delivery of Gigabit bandwidth to the desktop.

Specification Of BCM5464RA1KFBG

Features Of BCM5464RA1KFBG

Four fully-integrated 10BASE-T/100BASE-TX/1000BASE-T Gigabit Ethernet transceivers
RGMII, SGMII, and SerDes MAC interface options
1-Gbps line-side SerDes with RGMII MAC interface
Fully compliant with IEEE 802.3, 802.3u, and 802.3ab standards
0.13-micron CMOS—low power and cost
Supports copper or fiber in RGMII mode
Low power
- 750 mW per port
- Advanced power management
Trace matched output impedance
Line-side loopback
Low EMI emissions
Cable plant diagnostic
- Cable plant analyzer function detects cable plant impairments
- Link quality indication LED
- Automatic detection and correction of wiring pair swaps, pair skew, and pair polarity
- Automatic MDI/MDIX crossover at all speeds
Robust cable-sourced electrostatic discharge (CESD) tolerance
Support for jumbo packets up to 10 KB
IEEE 1149.1 (JTAG) boundary scan
Package: 256-pin BGA
