5SGXMA7H3F35C2N Field Programmable Gate Array FBGA-1152 Stratix V GX FPGA Chips

5SGXMA7H3F35C2N Field Programmable Gate Array FBGA-1152 Stratix V GX FPGA Chips​

Product Description Of 5SGXMA7H3F35C2N

5SGXMA7H3F35C2N Stratix V GX devices offer up to 66 integrated transceivers with 14.1-Gbps data rate capability. These transceivers also support backplane and optical interface applications.

5SGXMA7H3F35C2N is optimized for high-performance, high-bandwidth applications such as 40G/100G optical transport, packet processing, and traffic management found in wireline, and network test equipment markets.

Specification Of 5SGXMA7H3F35C2N

Features Of 5SGXMA7H3F35C2N

Technology

- 28 nm TSMC process technology
- 0.85V or 0.9V core voltage

Low-power serial transceivers
- 28.05Gbps transceiver on Stratix V GT devices
- Electronic dispersion compensation (EDC) supported by XFP, SFP+, QSFP, CFP optical modules
- Adaptive linear and judgement feedback equalisation
- Transmitter pre-emphasis and de-emphasis
- Individual channel dynamic reconfiguration
- On-chip instrumentation (EyeQ non-intrusive data eye monitoring)

Backplane capability
- 600 megabits per second (Mbps) to 12.5-Gbps data rate capability General Purpose I/O (GPIO)

General-purpose I/Os (GPIOs)
- 1.6Gbps LVDS
- 1066 MHz external memory interface
- On-Chip Termination (OCT)
- 1.2V to 3.3V interface for all Stratix V devices
Embedded HardCopy Block

- PCIe Gen3, Gen2 and Gen1 full stack, x1/x2/x4/x8 termination
Embedded transceiver hard IP

- Mezzanine Physical Coding Sublayer (PCS)
- Gigabit Ethernet (GbE) and XAUI PCSs
- 10G Ethernet PCS
- Serial RapidIO® (SRIO) PCS
- Common Radio Interface (CPRI) PCS
- Gigabit Passive Optical Network (GPON) PCS

Power management
- Programmable Power Technologies
- Quartus II Integrated PowerPlay Power Analysis

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
