ICS843002AG-01LFT Integrated Circuit Chip FemtoClock Crystal-To-3.3V LVPECL Frequency Synthesizer

ICS843002AG-01LFT Integrated Circuit Chip FemtoClock Crystal-To-3.3V LVPECL Frequency Synthesizer

Product Description Of ICS843002AG-01LFT
ICS843002AG-01LFT is a 2 output LVPECL synthesizer optimized to generate Ethernet reference clock frequencies. Using a 25MHz 18pF parallel resonant crystal, the following frequencies can be generated based on the 2 frequency select pins : 156.25MHz, 125MHz, and 62.5MHz. The ICS843002AG-01LFT uses our 3rd generation low phase noise VCO technology and can achieve 1ps or lower typical rms phase jitter, easily meeting Ethernet jitter requirements. The ICS843002AG-01LFT is packaged in a small 20-pin TSSOP package.

Features Of ICS843002AG-01LFT
Two 3.3V LVPECL outputs
Selectable crystal oscillator interface or LVCMOS single-ended input
Supports the following input frequencies:
156.25MHz, 125MHz and 62.5MHz
VCO range: 560MHz - 680MHz
RMS phase jitter @ 156.25MHz, using a 25MHz crystal (1.875MHz-20MHz): 0.54ps (typical)
Typical phase noise at 156.25MHz
Full 3.3V supply mode
Lead-Free package fully RoHS compliant
-30°C to 85°C ambient operating temperature
