AD5398BCPZ Integrated Circuit Chip 10-Bit DAC LFCSP-8 Digital To Analog Converter

AD5398BCPZ Integrated Circuit Chip 10-Bit DAC LFCSP-8 Digital To Analog Converter

Product Description Of AD5398BCPZ

AD5398BCPZ is a single 10-bit DAC with 120 mA output current sink capability. It features an internal reference and operates from a single 2.7 V to 5.5 V supply. The DAC is controlled via a 2-wire (I2C-compatible) serial interface that operates at clock rates up to 400 kHz.

AD5398BCPZ incorporates a power-on reset circuit, which ensures that the DAC output powers up to 0 V and remains there until a valid write takes place. It has a power-down feature that reduces the current consumption of the device to 1 µA maximum.

AD5398BCPZ is designed for autofocus, image stabilization, and optical zoom applications in camera phones, digital still cameras, and camcorders.

Specification Of AD5398BCPZ

Features Of AD5398BCPZ

120mA current sink
Available in 8-lead LFCSP package
2-wire (I2C-compatible) serial interface
10-bit resolution
Integrated current sense resistor
2.7 V to 5.5 V power supply
Guaranteed monotonic over all codes
Power-down to 0.5 µA typical
Internal reference
Ultralow noise preamplifier
Power-down function
Power-on reset

Applications Of AD5398BCPZ

Consumer Applications

Lens autofocus
Image stabilization
Optical zoom
Shutters
Iris/exposure
Neutral density (ND) filters
Lens covers
Camera phones
Digital still cameras
Camera modules
Digital video cameras/camcorders
Camera-enabled devices
Security cameras
Web/PC cameras
Industrial Applications

Heater control
Fan control
Cooler (Peltier) control
Solenoid control
Valve control
Linear actuator control
Light control
Current loop control
