ICE5AR4770AG Integrated Circuit Chip 700V CoolSET™ Fixed Frequency Power IC PG-DSO-12

ICE5AR4770AG Integrated Circuit Chip 700V CoolSET™ Fixed Frequency Power IC PG-DSO-12​

Product Description Of ICE5AR4770AG

ICE5AR4770AG is the 5th generation of fixed frequency integrated power IC (CoolSET™) optimized for off-line switch mode power supply in cascode configuration.

Specification Of ICE5AR4770AG

Features Of ICE5AR4770AG

100kHz maximum switching frequency with 700V integrated MOSFET
Power delivery of up to 15W with universal wide input range (85~300VAC) DCM design
Brown in protection, fast and robust start-up operation with cascode configuration
3 level selectable entry/exit active burst mode profile (optional)
Built-in digital soft-start
Cycle by cycle peak current limitation
Support both DCM and CCM operation with slope compensation
Integrated error amplifier to support direct feedback typical with non-isolated flyback topology
Digital frequency reduction with decreasing load for higher efficiency
Adjustable line input over voltage protection (optional)
VCC pin short to ground protection
OLP, output short, OTP with hysteresis and VCC over/under voltage protection
Auto-restart for all protection features

Applications Of ICE5AR4770AG
General purpose motor drive - variating frequency and voltage
Home appliances
Kitchen hoods
Residential air conditioning: Smart (IoT) and efficient cooling
Solid-State Circuit Breaker
