REF195GRUZ Integrated Circuit Chip 5V Low Dropout Voltage Reference IC TSSOP-8

REF195GRUZ Integrated Circuit Chip 5V Low Dropout Voltage Reference IC TSSOP-8

Product Description Of REF195GRUZ

REF195GRUZ Voltage References is made up of micropower, low dropout voltage (LDV) devices, providing stable output voltage from supplies as low as 100 mV above the output voltage and consuming less than 45 μA of supply current. In sleep mode, which is enabled by applying a low TTL or CMOS level to the SLEEP pin, the output is turned off and supply current is further reduced to less than 15 μA.

Specification Of REF195GRUZ

Features Of REF195GRUZ

Initial Accuracy: ±2 mV Max
Temperature Coefficient: 5 ppm/°C Max
Low Supply Current: 45 µA Max
Sleep Mode: 15 µA Max
Low Dropout Voltage
Load Regulation: 4 ppm/mA
Line Regulation: 4 ppm/V
High Output Current: 30 mA
Short-Circuit Protection

Applications Of REF195GRUZ
Portable instruments
ADCs and DACs
Smart sensors
Solar powered applications
Loop-current-powered instruments
