LSM6DS3TR Sensor IC 1.25mA 6-Axis iNEMO Inertial Measurement Unit LGA-14L Package
LSM6DS3TR Sensor IC 1.25mA 6-Axis iNEMO Inertial Measurement Unit LGA-14L Package
Description
Part Number:
LSM6DS3TR
Sensor Type::
6-Axis
Interface Type::
I2C, SPI
Output Type::
Digital
Acceleration::
2 G, 4 G, 8 G, 16 G
Sensitivity::
0.488 Mg/LSB
LSM6DS3TR Sensor IC 1.25mA 6-Axis iNEMO Inertial Measurement Unit LGA-14L Package
Product Description Of LSM6DS3TR
LSM6DS3TR is a system-in-package featuring a 3D digital accelerometer and a 3D digital gyroscope performing at 1.25 mA (up to 1.6 kHz ODR) in high performance mode and enabling always-on low-power features for an optimal motion experience for the consumer.
LSM6DS3TR supports main OS requirements, offering real, virtual and batch sensors with 8 kbyte for dynamic data batching.
Specifications Of LSM6DS3TR
6-axis
I2C, SPI
Digital
2 g, 4 g, 8 g, 16 g
0.488 mg/LSB
- 40 C
+ 85 C
1.71 V
3.6 V
1.25 mA
Moisture Sensitive:
Yes
Operating Supply Voltage:
1.8 V
Sensing Axis:
X, Y, Z
Unit Weight:
130 mg
Features Of LSM6DS3TR
Power consumption: 0.9 mA in combo normal mode and 1.25 mA in combo high-performance mode up to 1.6 kHz.
“Always-on" experience with low power consumption for both accelerometer and gyroscope
Smart FIFO up to 8 kbyte based on features set
Compliant with Android K and L
Hard, soft ironing for external magnetic sensor corrections
+2/+4/+8/+16 g full scale
+125/+250/+500/+1000/+2000 dps full scale
Analog supply voltage: 1.71 V to 3.6 V
Independent IOs supply (1.62 V)
Compact footprint, 2.5 mm x 3 mm x 0.83 mm
SPII2C serial interface with main processor data synchronization feature
Embedded temperature sensor
ECOPACK, RoHS and "Green" compliant
Applications Of LSM6DS3TR
Pedometer, step detector and step counter
Significant motion and tilt functions
Indoor navigation
Tap and double-tap detection
IoT and connected devices
Intelligent power saving for handheld devices
Vibration monitoring and compensation
Free-fall detection
6D orientation detection
