LT8641UX Integrated Circuit Chip 6Gbps HDMI2.0 4 Inputs 1 Output Switch IC QFN-128
Product Description Of LT8641UX
LT8641UX HDMI2.0 Switch features a 4:1 switch compliant to HDMI2.0/1.4 specification, max 6Gbps high speed data rate, adaptive equalization RX input and pre-emphasized TX output to support long cable application, no XTAL on board to save BOM cost.
LT8641UX HDMI2.0 Switch automatically detect the cable loss, and adaptively optimize the equalization setting. The CDR cleans the input data jtter, make it suitable for long cable and cascade application. It support RX termination resistor calibration to further improve signal integrity.
LT8641UX support DDC/SCDC compliant to HDMI2.0/1.4 specification. The integrated DDC and HPD switches further lower the cost of system manufacture, and simplify the routing on the system board. This package is QFN128 14mmx 14mm. It operate from -40°C to +85°C.
Features Of LT8641UX
4 inputs, 1output HDMI2.0 links
HDMI 1.4/2.0 compliant
Supports data rates up to 6.0Gbps
TX/RX side ODTs and management circuitry
Integrated HPD switch, DDC switch, and +5V Power indicator switch, greatly lowering the cost and simplifying the manufacturing process
Source/Sink connection detection for flexible system management
I2C control supported
Single 3.3V power supply
5V-tolerant DDC interfaces
Jitter cleaning PLL for better performance
No exteral crystal is needed
Adaptive equalization
Applications Of LT8641UX
Front panel buffer for advanced television (HDTV) sets
Standalone switcher
Multiple input displays
Projectors
AV receivers
