TPS613226ADBVT Integrated Circuit Chip 1.8A Switch Current Boost Converter SOT-23-5

TPS613226ADBVT Integrated Circuit Chip 1.8A Switch Current Boost Converter SOT-23-5​

Product Description Of TPS613226ADBVT

TPS613226ADBVT is a synchronous boost converter with only 6.5-µA quiescent current. The TPS61322 provides a power-supply solution for products powered by alkaline battery, NiMH rechargeable battery, or one-cell Li-ion battery. The boost converter is based on a hysteretic control topology using synchronous rectification to obtain maximum efficiency at minimal quiescent current. The TPS613226ADBVT also allows the use of small external inductor and capacitors. Higher than 90% efficiency is achieved at 10-mA load from 1.5-V input to 2.2-V output conversion.

Specification Of TPS613226ADBVT

Features Of TPS613226ADBVT

Operating input voltage range: 0.9 V to 5.5 V
Output voltage range: 1.8 V to 5.5 V
6.5-µA Quiescent current into VOUT pin
±3% Output voltage accuracy over temperature
Minimum switch peak-current limit:
- 0.42 A for TPS613223A
- 0.5 A for TPS61322
- 0.75 A for TPS613221A and TPS613226A
- 1.10 A for TPS613222A
Higher than 90% efficiency at 10-mA load from 1.5-V to 2.2-V conversion
Thermal shutdown protection

Applications Of TPS613226ADBVT
1-cell to 3-cell Alkaline or NiMH battery-powered applications
Gaming control
Tablet
Portable electronics
Medical equipment

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
