TPS92601BQPWPRQ1 Integrated Circuit Chip 1.5A Automotive Headlight LED Driver HTSSOP-20

TPS92601BQPWPRQ1 Integrated Circuit Chip 1.5A Automotive Headlight LED Driver HTSSOP-20​

Product Description Of TPS92601BQPWPRQ1

TPS92601BQPWPRQ1 is a dual-channel high-side-current LED driver. With full protection and diagnostics, this family of devices is dedicated for and ideally suited to automotive front lighting. The base of each independent driver is a peak-current-mode boost controller. Each controller has two independent feedback loops, a current-feedback loop with a high-side current-sensing shunt and a voltage-feedback loop with an external resistor-divider network.

Specification Of TPS92601BQPWPRQ1

Features Of TPS92601BQPWPRQ1

Input Voltage: 4 V–40 V (45 V Abs. Max.)
Output Voltage: 4 V–75 V (80 V Abs. Max.)
Fixed-Frequency Current-Mode Controller With Integrated Slope Compensation
Two Regulation Loops, Constant-Current Output and Constant-Voltage Output of Each Channel
High-Side Current Sense:
– 150-mV or 300-mV Sense Voltage (EEPROM Option)
– ±6-mV Offset (Achieving Approx. 4% or 2% LED Current Accuracy)
Output Voltage Sense, Internal Voltage Reference: 2.2 V ±5%
Integrated Low-Side NMOS-FET Driver: Peak Gate-Drive Current Typ. 0.7 A
Frequency Synchronization
Both PWM Dimming and Analog Dimming
Diagnostic:
– High-Side Current (LED Current) Available as Analog Output
– Open-LED and Short-to-GND Detection
– Shorted Output Protection
Internal Under- and Overvoltage Lockout

Applications Of TPS92601BQPWPRQ1
Automotive Headlight LED Driver
High-Brightness LED Applications
