PS8409AQFN48GTR2-C0 Integrated Circuit Chip 6 Gbps HDMI™ 2.0 Jitter Cleaning Repeater

PS8409AQFN48GTR2-C0 Integrated Circuit Chip 6 Gbps HDMI™ 2.0 Jitter Cleaning Repeater

Product Description Of PS8409AQFN48GTR2-C0
PS8409AQFN48GTR2-C0 is a HDMI™ repeater, or retimer, that removes jitter and fully supports HDMI 2.0 by supporting up to 6.0Gbps TMDS™ data rate. The device integrates a jitter tolerant TMDS receiver and a jitter cleaning TMDS transmitter for HDMI repeater applications. It removes both the data and clock jitter and the timing skews from the TMDS input to deliver a compliant and very low jitter HDMI output.

Features Of PS8409AQFN48GTR2-C0
Compliant to HDMI 2.0 specification up to 6.0Gbps
Supports up to 4K UHD formats, 24-bit color at 60 frames per second
Jitter cleaning PLL for the widest compliance and performance margin
Input can be DC coupled for native HDMI signaling
Input can be AC coupled for personal computer level shifting applications
Programmable receiver equalization to compensate for PCB and/or connector looses
CrystalFree™ technology – no external crystal or reference clock is needed
Superior Intra-pair and Inter-pair de-skewing performance
Built-in DDC Active buffering
Supports TMDS output pre-emphasis
Flexible pin and I2C control mode options
Low power consumption
Automatic power down management
Automatic output squelch circuit for fail-safe operation and power management
3.3V and 1.2V power supplies
Operating temperature range availability: 0° to 70°C (commercial), -40° to 85°C (industrial)
ESD: HBM 7kV

Applications Of PS8409AQFN48GTR2-C0
PC mother board or graphics card
Television
Docking stations
AV Receiver
Active cables
