STA5635 Wireless Communication Module Automotive Universal GNSS RF Receiver

STA5635 Wireless Communication Module Automotive Universal GNSS RF Receiver

Product Description Of STA5635

STA5635 is a fully integrated RF front-end able to support different bands (L1, L2, L5, L6 and L) thanks to a programmable and flexible RF-IF chain driven by a fractional PLL. In particular, G5RF is able to manage all the GNSS constellations available and planned in the nextfuture like GPS, Galileo, Glonass, BeiDou, IRNSS and QZSS.


Features Of STA5635
Multi GNSS band support (L1/E1, L2C,L5/E5/E6/L6 and L band)
Programmable IF bandwidth (7 or 13 MHzrange)
1.62 V to 3.6 V supply voltage range
Smart digital interface (JESD207-COMPATIBLE)
Fractional-N synthesizer with embedded loopfilter
SPI interface for full programmability andinterface to transmit L-band data bit
2 Bit A/D converter
Operating temperature (-40 °C, 105 °C)
CMOS040 technology
QFN5x5 32leads package
