Product Details:
|
Part Number: | NCV8460ADR2G | Output Configuration: | High Side |
---|---|---|---|
Voltage - Load: | 6V ~ 36V | Current - Output (Max): | 6A |
Rds On (Typ): | 60mOhm | Operating Temperature: | -40°C ~ 150°C (TJ) |
Highlight: | NCV8460ADR2G Integrated Circuit Chip,High Side Driver Integrated Circuit Chip,SOIC-8 Integrated Circuit Chip |
NCV8460ADR2G Integrated Circuit Chip 6A Self Protected High Side Driver SOIC-8
Product Description Of NCV8460ADR2G
NCV8460ADR2G is a fully protected High−Side driver that can be used to switch a wide variety of loads, such as bulbs, solenoids and other acuators. The device is internally protected from an overload condition by an active current limit and thermal shutdown. A diagnostic output reports ON and OFF state open load conditions as well as thermal shutdown.
Specification Of NCV8460ADR2G
Part Number: | NCV8460ADR2G |
High Side | |
1 Output | |
2 A | |
6 A | |
120 mOhms | |
40 us | |
30 us | |
6 V to 36 V | |
- 40 ℃ | |
+ 150 ℃ | |
SMD/SMT | |
SOIC-8 | |
Product Type: | Power Switch ICs - Power Distribution |
Supply Voltage - Max: | 36 V |
Supply Voltage - Min: | 6 V |
Features Of NCV8460ADR2G
Short Circuit Protection
Thermal Shutdown with Automatic Restart
CMOS compatible control input
Open Load Detection in On and Off State
Diagnostic Output
Undervoltage and Overvoltage Shutdown
Loss of Ground Protection
ESD protection
Slew Rate Control for Low EMI Switching
Very Low Standby Current
Applications Of NCV8460ADR2G
Switch a Variety of Resistive, Inductive and Capacitive Loads
Can Replace Electromechanical Relays and Discrete Circuits
Automotive / Industrial
Block Diagram Of NCV8460ADR2G
