Product Description Of TPS22990NDMLR
TPS22990NDMLR device is a 3.9-mΩ, single-channel load switch with a controlled and adjustable turn on and integrated PG indicator.
The TPS22990NDMLR devices contain an N-channel MOSFET that can operate over an input voltage range of 0.6 V to 5.5 V and can support a maximum continuous current of10 A. The wide input voltage range and high current capability enable the devices to be used across multiple designs and end equipments. 3.9-mΩ On-resistance minimizes the voltage drop across the load switch and power loss from the load switch.
Specification Of TPS22990NDMLR
Load Switch
1 Output
10 A
4.8 mOhms
34 us
5.4 us
600 mV to 5.5 V
- 40 C
+ 105 C
Supply Voltage - Max:
5.5 V
Supply Voltage - Min:
600 mV
Unit Weight:
8.100 mg
Feature Of TPS22990NDMLR
Integrated Single Channel Load Switch
VBIAS Voltage Range: 2.5 V to 5.5 V
VIN Voltage Range: 0.6 V to VBIAS
On-Resistance
RON = 3.9 mΩ (typical) at VIN = 5 V
(VBIAS = 5 V)
RON = 3.9 mΩ (typical) at VIN = 3.3 V
(VBIAS = 3.3 V)
10-A Maximum Continuous Switch Current
Quiescent Current
IQ,VBIAS = 63 µA at VBIAS = 5 V
Shutdown Current
ISD,VBIAS = 5.5 µA at VBIAS = 5 V
ISD,VIN = 4 nA at VBIAS = 5 V, VIN = 5 V
Controlled and Adjustable Slew Rate through CT
Power Good (PG) Indicator
Quick Output Discharge (QOD) (TPS22990 Only)
3-mm × 2-mm SON 10-pin Package with Thermal Pad
ESD Performance Tested per JESD 22
2-kV HBM and 1-kV CDM
Applications Of TPS22990NDMLR
Notebooks, Chromebooks and Tablets
Desktop PC and Industrial PC
Solid State Drives (SSDs)
Servers
Telecom systems
