BTN7975B Integrated Circuit Chip Integrated High Current PN Half Bridge Motor Drive

BTN7975B Integrated Circuit Chip Integrated High Current PN Half Bridge Motor Drive

Product Description Of BTN7975B
BTN7975B is an integrated high current half bridge for motor drive applications. It is part of the NovalithIC™ family containing one p-channel highside MOSFET and one n-channel lowside MOSFET with an integrated driver IC in one package. Due to the p-channel highside switch the need for a charge pump is eliminated thus minimizing EMI. Interfacing to a microcontroller is made easy by the integrated driver IC which features logic level inputs, diagnosis with status flag, slew rate adjustment, dead time generation and protection against overtemperature, overvoltage, undervoltage, overcurrent and short circuit.

BTN7975B provides a cost optimized solution for protected high current PWM motor drives with very low board space consumption.

Feature Of BTN7975B
Path resistance of max.30.5 m92 @ 150.C (typ. 16 mQ @ 25 °C)
High Side: max. 12.8 mQ @ 150 °C (typ. 7 mQ @25 °C)
LowSide:max.17.7mQ@150°C(typ.9mQ@25°C)
Low quiescent current oftyp.7 puA @ 25 °C
PWM capability of up to 25 kHz combined with active freewheeling
Switched mode current limitation for reduced power dissipation in overcurrent
Current limitation level of 50 A min. I 70 A typ. (low side)
Status flag diagnosis
Overtemperature shut down with latch behaviour
Overvoltage lock out
Undervoltage shut down
Driver circuit with logic level inputs
Adjustable slew rates for optimized EMI
Operation up to 28V
Green Product (RoHS compliant)
AEC Qualfied
